Guangzhi’s automated pail filling line handles 15 pails/min of paints/latex with ±0.5% accuracy. ATEX-certified, 80% labor reduction & near-zero waste. Request datasheet!
*High-Speed, Splash-Free Filling for Industrial Chemicals (5–25L Pails)*
Shanghai Guangzhi Automation’s GZ-PFL600 Series integrates robotic denesting, precision filling, and leak-proof capping to automate packaging of paints, latex emulsions, and solvent-based waterproofing compounds. Engineered for corrosive and viscous media (up to 100,000 cP), this ATEX/CE-certified line achieves ±0.5% weight accuracy at 15 pails/minute, reduces labor by 80%, and eliminates spills with proprietary splash-control technology.
Contamination-Free Filling
Stainless Steel Drum Filler (316L SS): ATEX-compliant explosion-proof version for solvents; handles viscosities 500–100,000 cP.
Anti-Splash Nozzles: Submerged filling + nitrogen inertization prevents oxidation/foaming in paints.
Automated Workflow
Robotic Denester: Unstacks 25 nested pails/min; adaptive grippers for deformed containers.
Net Weight Filler: Load-cell-controlled servo pumps (±0.5% accuracy); auto-tares container weight variations.
Torque-Control Capper: Applies tamper-evident lids with 5–30 Nm force (programmable).
Zero-Downtime Architecture
Modular Design: Quick-change tooling for pail sizes (12–16" diameter) in <5 mins.
Self-Diagnostic PLC: Predictive maintenance alerts for fill heads/conveyors via 15" HMI.
Hazard-Safe Operation
ATEX Zone 1 Certification: Explosion-proof sensors/motors for solvent vapors (IP66 enclosure).
Containment Drip Pans: Capture overfills; comply with EPA/OSHA chemical spill regulations.
| Component | Specification |
|---|---|
| Line Throughput | 15 pails/minute (25L) |
| Filling Accuracy | ±0.5% (gravimetric mode) |
| Pail Compatibility | Plastic/steel: 5–25L, ?300–400mm, H≤450mm |
| Viscosity Range | 500–100,000 cP |
| Capping Force | 5–30 Nm (adjustable) |
| Power | 380V/50Hz, 18 kW |
| Air Supply | 0.7 MPa, 1.2 m3/min |
| Line Footprint | 12,000 × 3,500 mm (L×W) |
| Compliance | ATEX, CE, OSHA, ISO 80079 |
| Metric | GZ-PFL600 Automated Line | Manual Operation |
|---|---|---|
| Output (8h shift) | 7,200 pails | 900 pails |
| Labor | 1 operator (monitor) | 4 operators |
| Material Waste | <0.2% | 3–8% |
| Spill Incidents | 0 | 2–5 daily |
| ROI Period | 10–14 months | N/A |
Paint/Latex: Splash-free filling preserves pigment dispersion; stainless steel resists abrasives.
Solvent-Based Sealants: Nitrogen purging prevents skinning; conductive hoses dissipate static.
Waterproofing Slurries: High-pressure piston filler (25 bar) for cementitious materials.
APPLICABLE BARREL TYPE
