Semi Automatic Cap Press Machine for Jerrycan and Bucket Lid Sealing

Semi-automatic lid sealer for 5-60L containers: 45 units/hour, ±3% torque accuracy. Leak-proof sealing. CE/FDA certified. Free demo!

  • Brand: glzon
  • Model: GZM_30L

CapPress Pro CP-200 Series

Semi-Automatic Lid Sealing Machine for Jerrycans & Pails

Industrial-Grade Seal Integrity. Simple Operation. 5-Minute Changeover.

Semi-Automatic Capping Machine


Technical Specifications

Parameter

CP-210 (Standard)

CP-220H (Heavy-Duty)

CP-230F (Food Grade)

Container Compatibility

5-30L Jerrycans & Pails

10-60L Containers

5-20L Food Pails

Lid Types

Screw Caps, Snap Lids

Threaded Drums Lids

Tamper-Evident Seals

Sealing Force

0-800 N (Adjustable)

0-1500 N

0-600 N

Torque Accuracy

±3% (0-30 N·m)

±5% (0-50 N·m)

±2% (0-20 N·m)

Cycle Time

8 sec/unit

10 sec/unit

8 sec/unit

Throughput

45 units/hour

36 units/hour

40 units/hour

Power

0.5 kW (Pneumatic)

0.8 kW (Electro-Pneumatic)

0.6 kW (Pneumatic)

Air Consumption

90 L/min @ 0.6 MPa

120 L/min

100 L/min

Seal Integrity Test

>0.8 bar (ISO 8317)

>1.2 bar

>0.9 bar (ASTM D4991)

Material Contact

Powder-Coated Steel

304 SS Guards

316L SS + FDA UHMW

Safety

Dual-Hand Control

Light Curtain + Emergency Stop

Same + IP69K Rating

Changeover Time

<5 min (Tool-Free)

<8 min

<5 min

Footprint (L×W×H)

1000×800×1600mm

1200×900×1800mm

1000×800×1600mm


Core Innovations

1. SmartSeal? Adaptive Press System

Key Features:

  • Pressure-Adaptive Jaws:

    Lid Material

    Force Adjustment

    Plastic

    150-400 N

    Metal

    400-800 N

    Composite

    200-600 N

  • Leak Prevention:

    Defect

    Detection Sensitivity

    Cross-threading

    >0.5mm misalignment

    Damaged Gasket

    Compression <85%

2. Universal Tooling System

Quick-Change Kits:

Kit Type

Compatibility

Swap Time

Jerrycan (Rectangular)

5L/10L/20L/30L

45 sec

Round Pail (?200-400mm)

10-60L buckets

60 sec

Drum Lid (?80-120mm)

20-220L drums

75 sec


Industry Applications

Chemicals & Lubricants

Feature

Benefit

Vapor Containment

>99% seal integrity at 0.9 bar

Solvent Resistance

Viton? gasket option

ATEX Compatibility

Grounded static control (<10? Ω)

Food & Beverage

  • EHEDG-compliant design (R1.1)

  • Sanitary quick-release clamps

  • USDA/3-A certified contact surfaces

Paints & Coatings

Challenge

Solution

Skin-tight sealing

N?-assisted lid placement

VOC leakage

Carbon-filled gaskets

Metallic flake settling

Vibration-free operation


Performance Validation

Hazardous Chemical Leak Test (UN 6.1):

? Test Standard: ISO 8317 Child-Resistant Packaging
? Method:
- Filled with acetone @ 40°C
- Stored inverted for 7 days
? Result:
0% leakage at 0.8 bar internal pressure

Smart Control System

7" Touchscreen with SealOS?

Memory Functions:

  • 50+ Preset Programs:

    Container Type

    Precision Setting

    20L Jerrycan

    18 N·m ±0.5 N·m

    30L Pail

    22 N·m ±0.7 N·m

  • Predictive Maintenance:

    Component

    Alert Threshold

    Air Cylinder

    Pressure drop >10%

    Jaw Wear

    Alignment >0.3mm


Certifications

? CE EN 415-7
? ANSI/UL 2054 Child-Resistant
? FDA 21 CFR 177.2600
? ISO 9001:2015
? ATEX 2014/34/EU (Option)

Operational Workflow

1. Place container → 2. Position lid →
3. Dual-hand start → 4. Auto jaw alignment →
5. Pressure-controlled sealing → 6. Torque verification →
7. Release finished unit

Cycle Time: 8 seconds


Pricing & Packages

Model

Base Price

Popular Bundle

Bundle Price

CP-210

$12,500

Standard + Jerrycan Kit

$13,800

CP-220H

$16,200

Heavy-Duty + Drum Lid Kit

$18,500

CP-230F

$14,800

Food Grade + CIP System

$16,900

ROI Calculation:

? Labor Savings:
- Manual sealing: 15 units/hour
- CP-210: 45 units/hour (200% increase)
- Labor cost reduction: $28,000/year
? Quality Savings:
- Reduced leakage claims: $15,000/year
- Elimination of rework: $9,000/year
? Payback Period: 6-9 months


APPLICABLE BARREL TYPE

Drum Filling Machine

COMPANY PROFILE

Shanghai Guangzhi Automation Equipment Co., Ltd. is a production and trading company specializing in the weighing industry. We are located in Shanghai, China's economic city, with convenient transportation and export ports all over the world. We cooperate with state-owned factories and international companies, and the quality is guaranteed.

We mainly focus on providing customers with weighing solutions, from commercial scales to industrial weighing machines. Such as pneumatic valve bag packaging machine, dry mix mortar bag packaging machine, cement packaging machine, natural stone powder packaging machine, flour powder packaging machine, wheat packaging machine, potato starch packaging machine, air packaging machine, granule bag packaging machine, grain packaging machine, fertilizer bag packaging machine, lubricant filling machine, 200 kg drum filling machine, 216L drum filling machine, 208L drum filling machine, ton barrel filling machine, IBC barrel filling machine, jumbo bag packaging machine, ton bag packaging machine, 30L pail filling machine, 50L pail asphalt filling machine, ATEX barrel filling machine, explosion-proof filling machine, etc.

Drum Filling Machine

Company Certificate

Drum Filling Machine

Our office and workshop

Consulting-Design-Procurement-Processing-Production-Installation-Debugging-Training-Maintenance

Drum Filling Machine


This is a partial Drum Filling MachineDrum Filling Machine

service for us

in China.

Over 30 years of experience, every time we produce in

Shanghai, our friends can visit our factory at any time.






Brand components

We will ensure that our company's equipment has safety, stability, high efficiency and intelli-gent technology, so as to meet your needs, we can also cooperate with you in selecting in-ternational product brand production and business.

Drum Filling Machine


Our service

Complete solution provided

Telephone exchange joint business design plan, you can also visit our company ; we have a good environmental office vehicle,you can visit from time to time.


Duty after death

Our music team has a strong heart, and the customer's suspicions are also the purpose 24 hours of phone cell service and listing to the conversation at any time.


Technology group

We have a wealth of technical personnel and our technical team has been developing technical skills for over ten years.


Successful collaboration

Our factory in Shanghai. China provides free training for our technical staff.Better guarantee good product safety , our company provides safety, convenience, high efficlency packaging servic.

packge and delivery

Multiple Transportation way :Express(Fedex/DHL/TNT/EMS/UPS etc),air and shipping for your choose

Drum Filling Machine

FAQs

Our in-house designers and engineers have produced countless great designs for customers from different industries

1
Can we get your free samples?
Samples can be offered for free. But courier cost for the samples should be at buyer's account.
2
Can you print our LOGO in flatware set?
Yes.we can print the logo on the flatware set as your requirements.Embossed, laser,stamped and engraved are available.
3
How long is the delivery time of sample?
Samples from stock can be sent within 1-3 days. New produced samples will be sent within 5-15 days.
4
Is there any MOQ for what I purchase?
Yes, we have MOQ for mass production. Different item with different package has different MOQ. Please contact us for more details.
5
Do you accept OEM or ODM services?
OEM and ODM are accepted!
6
What is 18-10 Stainless Steel Flatware?
18-10 refers to the composition of stainless steel. It contains 18% chromium and 10% nickel for excellent strength and corrosion resistance.

CONTACT US

Skype: fayfaywang1027

QQ: 429682794

Whatsapp: 008618016442021

E-mail: glzoncn@163.com

https://glzon.en.alibaba.com/

cel: +0086 18016442021
